100L to 10000L Dry powder horizontal ribbon blender double helical industrial flour paddle mixer mixing blending machine
Intorduce:
Used for mixing powder or wet materials to make main and auxiliary materials of different proportions mix evenly.The machine is made of stainless steel where it contacts with materials. The gap between pulp leaves and barrel body is small and there is no dead Angle in mixing. Sealing device is set at both ends of stirring shaft to prevent material from exuding.Widely used in pharmaceutical, chemical, food and other industries.
Working principle:
The ribbon mixer consists of a trough, a spiral agitating blade and a transmission component; the spiral blade is generally made of two or three layers, the outer spiral encloses the material from both sides to the center, and the inner spiral spirals the material from the center to the inside.
Conveyed to form a convective mix.
The model consists of three parts: the transmission mechanism, the horizontal cylinder groove and the spiral belt.
The mixer is rotated by the inner and outer spiral belts to mix the materials, and the mixture is evenly mixed in a short time.
Product parameters
| specification | | WLDH-0.3 | WLDH-0.5 | WLDH-1 | WLDH-2 | WLDH-3 | WLDH-4 | WLDH-5 | WLDH-6 | WLDH-8 | WLDH-10 | WLDH-15 | WLDH-20 | WLDH-30 |
| wrking capacity(m³) | | 0.18 | 0.3 | 0.6 | 1.2 | 1.8 | 2.4 | 3 | 3.6 | 4.8 | 6 | 9 | 12 | 18 |
| working capacity(kg) | | 200 | 300 | 600 | 1200 | 1800 | 2500 | 3000 | 3600 | 4800 | 6000 | 9000 | 12000 | 15000 |
| speed (r/min) | | 62 | 62 | 49 | 33 | 33 | 27 | 27 | 27 | 22 | 14 | 14 | 14 | 12 |
| power(kw) | | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 75 | 90 | 110 |
| weight | | 600 | 900 | 1200 | 2000 | 2500 | 3500 | 4000 | 4500 | 5000 | 6000 | 7500 | 10500 | 13000 |
| Length | | 2280 | 2670 | 3140 | 3860 | 4460 | 4950 | 5280 | 5530 | 5100 | 5610 | 5820 | 6300 | 7000 |
| width | | 680 | 780 | 980 | 1200 | 1300 | 1400 | 1550 | 1560 | 1720 | 1750 | 2000 | 2350 | 2600 |
| Height | | 880 | 1240 | 1400 | 1650 | 1700 | 2000 | 2100 | 2200 | 2500 | 2650 | 2900 | 3160 | 3350 |
